Panel Flexible Wire 10mm LSZH 0.6/1kV Green/Yellow Per Metre Eltech

BRAND: Eltech
SKU: PW0100
$8.70 List price: $11.60
+ −
30 Days Return Electricians Unlock Trade Access
Eltech panel flexible wire features 10mm conductor, LSZH insulation, 0.6/1kV rating and green/yellow earth colours. Ideal for switchboard earth wiring.

Alternatively Known As: Panel Flex Earth Cable 10 mm² LSZH, Eltech LSZH Earth Wire 10 mm²

Technical Specifications
  • Conductor Size: 10 mm²
  • Conductor Material: Class 6 plain annealed copper (10 mm² and above)
  • Insulation: X‑HF‑110 cross‑linked polyolefin LSZH, flame retardant, UV, ozone, oil and chemical resistant
  • Voltage Rating: 0.6/1 kV
  • Operating Temperature: – 40 °C to 125 °C
  • Standards: AS/NZS 5000.1, AS/NZS 3808, AS/NZS 1125, AS/NZS 1660 series, AS/NZS 3008.1
  • SAA Certificates: SAA241737, SAA241738
  • Dimensions (H x L x W): 5mm x 10000mm x 5mm
  • Weight: 0.1 kg
Key Features
  • Low Smoke Zero Halogen (LSZH) insulation improves safety in confined spaces
  • High thermal tolerance up to 125 °C
  • Resistant to oil, petrol, Skydrol, UV and ozone exposure
  • Conductor stranding suited for flexible installations and switchboard earthing
  • Manufactured and certified to multiple AS/NZS standards
Applications
  • Switchboard earthing and panel earth wiring
  • Instrumentation, control systems wiring
  • Mains and sub‑mains earth conductors in industrial/commercial installations
Standards & Compliance
  • AS/NZS 5000.1
  • AS/NZS 3808
  • AS/NZS 1125
  • AS/NZS 1660.1
  • AS/NZS 1660.2.1
  • AS/NZS 1660.2.2
  • AS/NZS 1660.2.3
  • AS/NZS 1660.3
  • AS/NZS 1660.5.4
  • AS/NZS 1660.5.6
  • AS/NZS 3008.1
Environmental Benefits
  • LSZH insulation reduces toxic and corrosive halogen emissions during fire
  • Durable insulation and copper conductor support long service life, reducing waste
Warranty Information

7‑year warranty when purchased and installed by a licensed electrician according to manufacturer’s instructions and proof of purchase. Refer to Eltech Terms & Conditions of Trade. ([eltech.com.au](https://eltech.com.au/wp-content/uploads/2022/07/Terms-and-Conditions-of-Trade-Eltech.pdf?utm_source=openai))

Available Now

Available through authorised Australian electrical wholesalers and Eltech Australia, supplied in cut‑to‑length or drum form.
