Panel Flexible Wire 25mm LSZH 0.6/1kV Green/Yellow Per Metre Eltech
Eltech panel flexible wire features 25mm conductor, LSZH insulation, 0.6/1kV rating and green/yellow earth colours. Ideal for switchboard earth wiring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Panel Flex Earth Wire 25 mm² LSZH Eltech
Technical Specifications
- Conductor Size: 25 mm² flexible copper
- Insulation: Low Smoke Zero Halogen (LSZH) X‑HF‑110 cross‑linked polyolefin
- Voltage Rating: 0.6/1 kV
- Operating Temperature: –40 °C to +125 °C
- Colour: Green/Yellow (earth)
- Packaging: Timber drum 100 m, cut‑to‑length from 10 m minimum
- Dimensions (H x L x W): 5mm x 100000mm x 25mm
- Weight: 0.5 kg
Key Features
- LSZH insulation for reduced smoke and halogen emissions in fire scenarios
- Flexible single‑core copper suitable for panel and switchboard earth wiring
- High voltage rating of 0.6/1 kV for reliable power distribution
- Green/yellow earth‑colour coding for compliance with electrical safety
- Resistant to seawater, oil, petrol, Skydrol, UV and ozone
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 Wiring Rules.
Applications
- Earth wiring in switchboards and panels
- Power distribution earth conductors in residential, commercial and industrial installations
- Panel and instrument control systems requiring safety earth conductors
Standards & Compliance
- AS/NZS 3000 Wiring Rules
- AS/NZS 5000.1 (conductor insulation standards for panel flex)
Environmental Benefits
- LSZH insulation reduces toxic smoke and halogen gas emissions in fires
- Robust insulation extends service life, reducing waste
Warranty Information
7‑year warranty when installed by a licensed electrician per Eltech Terms & Conditions.
Available Now
Available through authorised Australian distributors and Eltech’s network; cut‑to‑length from 10 m, drum lengths 100 m.
