Photoelectric Proximity Sensor RT-P2231 IP67 Rated Fast Response Time SICK

BRAND: SICK
SKU: 1063190
$517.70 List price: $650.70
+ −
30 Days Return Electricians Unlock Trade Access
The Photoelectric Proximity Sensor RT-P2231 is designed for industrial automation, featuring a sensing range of 60 mm to 900 mm and an IP67 rated enclosure for dust

Alternatively Known As: Photoelectric proximity sensor, Background suppression sensor, Infrared proximity switch, PNP photo sensor

Technical Specifications
  • Supply voltage: 10 V DC to 30 V DC
  • Current consumption: 20 mA
  • Switching output: PNP, dark switching
  • Output current max: ≤ 100 mA
  • Response time: 2 ms
  • Switching frequency: 250 Hz
  • Connection type: Male M12, 4-pin connector
  • Protection class: III
  • Enclosure rating: IP67
  • Operating temperature: -40 °C to +60 °C
  • Storage temperature: -40 °C to +75 °C
  • Housing material: Plastic, ABS
  • Light source: Infrared LED
  • Focus angle: 7°
  • Light spot size at 500 mm: Ø 20 mm
  • Adjustment: Potentiometer with 9 turns
  • Circuit protection: Types A, C, D
  • Dimensions (H x L x W): 99mm x 49mm x 21mm
  • Weight: 0.175 kg
Key Features
  • Photoelectric proximity sensor with background suppression
  • Sensing range from 60 mm to 900 mm
  • Infrared LED light source with 7° focus and angle of dispersion
  • Potentiometer adjustment with 9 turns for sensitivity tuning
  • IP67 rated enclosure for dust and water protection
  • Shock and vibration resistant according to IEC 68
  • Dark switching mode with PNP output
  • Fast response time of 2 ms and switching frequency of 250 Hz
Professional Installation Requirements
  • Installation by a qualified technician or electrician is recommended to ensure proper wiring and sensor alignment for optimal performance.
Applications
  • Industrial automation for object detection
  • Safety and control systems requiring precise proximity sensing
  • ZoneControl applications in manufacturing and processing
Standards & Compliance
  • AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Low power consumption with 20 mA current draw
  • Durable ABS plastic housing extends product life reducing waste
  • Complies with China RoHS for hazardous substance restrictions
Warranty Information

Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.

Available Now

The SICK RT-P2231 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and safety control applications.
