PIR Motion Sensor 1200W 360 Degree Corner Mount IP65 White LANX
This LANX corner-mount PIR motion sensor handles up to 1200W max load with selectable 180° or 360° detection range and up to 12m detection distance. It's IP65 rated for outdoor use, with adjustable time delay from 10 seconds to 15 minutes and light sensitivity from under 3 to 2000 lux. The unit complies with AS/NZS 3000 Wiring Rules for electrical installation. Full specifications and mounting details are available further down the page.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Voltage: 220-240V AC
- Power Frequency: 50/60Hz
- Ambient Light Sensitivity: <3-2000 LUX (adjustable)
- Time Delay: Min 10 sec ± 3 sec, Max 15 min ± 2 min
- Rated Load: Max 1200W
- IP Class: IP65
- Detection Range: 180°/360°
- Detection Distance: 12m max (<24°C)
- Working Temperature: -20 to +40°C
- Working Humidity: <93% RH
- Power Consumption: approx 0.5W
- Installation Height: 1.8-2.5m
- Detection Moving Speed: 0.6-1.5 m/s
- Dimensions (H x L x W): 60mm x 100mm x 90mm
- Weight: 0.3 kg
Key Features
- IP65 rated for weather resistance and outdoor use
- Includes corner mount bracket for 90 degree corner installation
- Adjustable ambient light sensitivity from <3 to 2000 LUX
- Time delay adjustable from minimum 10 seconds to maximum 15 minutes
- Detection range options of 180° or 360°
- Maximum detection distance of 12 meters
- Low power consumption approximately 0.5W
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and optimal sensor performance.
Applications
- Outdoor lighting control for residential and commercial properties
- Security lighting activation
- Pathway and garden lighting automation
- Warehouse and industrial area lighting control
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Reduces energy consumption by activating lighting only when movement is detected
- Helps lower carbon footprint through efficient lighting control
Warranty Information
1 year warranty covering manufacturing defects and workmanship.
Available Now
The Lanx Motion Sensor 1200W is available now for immediate purchase. Ideal for outdoor lighting control in residential, commercial, and industrial settings.
FAQ
Q: What detection range and load does this corner-mount sensor support?
A: It offers selectable 180° or 360° detection up to 12m range, and supports a maximum load of 1200W.
Q: Is this sensor suitable for outdoor installations?
A: Yes, it's IP65 rated for weather resistance and backed by a 1-year warranty covering manufacturing defects and workmanship.
A PIR motion sensor with 180 degree coverage and IP44 rating suits general outdoor entrances.
An outdoor motion sensor light with 360 degree coverage suits wider detection areas.
A standalone PIR motion sensor recessed into the ceiling suits indoor detection zones.
