PIR Motion Sensor 180 Degree IP44 Surface Mount Black 3A Lighting
This 3A Lighting PIR motion sensor offers 180° detection with a maximum distance of 12m, suited for LED lighting control in homes and offices. It's surface mounted with IP44 rating, manual override and adjustable ambient light sensitivity from under 3 to 2000 lux. The sensor complies with AS/NZS 3000 Wiring Rules for electrical installation. Full specifications and installation details are covered further down the page.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Input Voltage: 220V-240V
- Detection Range: 180°
- Installation Height: 2.2m-4.0m
- Detection Motion Speed: 0.6-1.5m/s
- Detection Distance: 12m Max
- Time Delay: Min. 10Sec + 3Sec, Max. 15min + 2min
- Ambient Light Sensitivity: <3-2000 LUX (adjustable)
- Wiring: 3 wires
- Dimensions (H x L x W): 50mm x 80mm x 80mm
- Weight: 0.3 kg
Key Features
- Surface mounted design
- 180° detection range
- Manual override function
- Suitable for LED lighting
- IP44 rated for dust and water resistance
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical safety standards.
Applications
- Residential: Home security and automation
- Commercial: Office lighting control and security
- Industrial: Warehouse and factory motion detection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy saving by automatically controlling lighting based on occupancy
- Reduces unnecessary power consumption and carbon footprint
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Infrared Motion Sensor 180° IP44 Rated in Black Finish is available now for immediate purchase. Ideal for enhancing security and energy efficiency in residential, commercial, and industrial applications.
FAQ
Q: What is the detection range and angle of this PIR sensor?
A: It covers a 180° detection range with a maximum distance of 12m, and includes manual override functionality.
Q: Is this sensor suitable for LED lighting control?
A: Yes, it's designed for LED lighting control with adjustable time delay and light sensitivity settings, backed by a 1-year warranty.
