PL 12 / 25 Crimp & Insul Set 4P | 660V to 3300V | IP55 Rated | Quick Release by Ausproof
The PL 12 / 25 Crimp & Insul Set 4P is designed for robust electrical connections in hazardous environments, featuring a voltage range of 660V to 3300V and IP55 ingress protection. Ideal for mining and commercial installations, it offers quick release for easy disconnection and durable stainless steel construction for long-lasting performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PL 12 / 25 Crimp & Insul Set 4P 95 mm^2
Brand: Ausproof
SKU: RS1965
Alternatively Known As: Ex-certified industrial plug, flameproof plug and receptacle, mining electrical connector, hazardous area plug, quick release industrial plug
Technical Specifications
- Voltage Range: 660V to 3300V
- Current Ratings: 300A and 425A
- Material: Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 2 tests at 25.0kA for 0.2 seconds
- Through Fault Current (Earth): 2 tests at 8.0kA for 0.2 seconds
- AC High Voltage Withstand (Phase): 8.6kV for one minute
- AC High Voltage Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: Rated for 300A and 425A
- Compliance: AS/NZS 1299, IEC 60079-0, IEC 60079-1
- Dimensions (H x L x W): 250mm x 300mm x 150mm
- Weight: 10.7 kg
Key Features
- Quick Release mechanism for easy disconnection
- Single piece contacts to prevent hot joints
- Easy termination and flameproof repair
- Full solid earth connectivity throughout the product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone Protection Cover included
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Installation must be performed by a qualified electrician experienced with hazardous area electrical equipment to ensure compliance with safety standards and proper flameproof sealing.
Applications
- Mining and tunnelling operations
- Commercial electrical installations
- Group 1 hazardous environments requiring flameproof equipment
Standards & Compliance
- Complies with AS/NZS 1299 - Electrical Equipment for Explosive Atmospheres
Environmental Benefits
- Durable stainless steel construction reduces need for frequent replacements
- Flameproof repairability minimizes waste by allowing on-site body casting replacement
- Energy efficient design reduces electrical losses
Warranty Information
Warranty details available upon request; typically includes coverage against manufacturing defects.
Available Now
The Ausproof PL 12 / 25 Crimp & Insul Set 4P 95 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications requiring robust and flameproof electrical connections.
