Industrial Receptacle 660V IP55 Quick-Release Ausproof
The Ausproof RS2350 is an Ex-certified PL 16/25 Crimp & Insulation 4-pin receptacle set engineered for heavy-duty $50\text{ mm}^2$ cable terminations in mining, tunnelling, and Group 1 hazardous locations. Constructed from high-integrity stainless steel, this industrial receptacle operates seamlessly across a voltage range of 660V to 3300V with a current rating up to 425A. It utilizes a quick-release design paired with single-piece contacts to effectively eliminate hot joints, ensuring complete phase-to-phase segregation with earth. This IP55-rated unit delivers an easily repairable flameproof construction that allows for efficient on-site maintenance while strictly complying with AS/NZS 1299 standards
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Voltage Range: 660V to 3300V
- Current Ratings: 300A to 425A
- Material: Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
- Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
- AC High Voltage Withstand (Phase): 8.6kV for one minute
- AC High Voltage Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: Rated for 300A and 425A
- Weight: Receptacle 10.7kg, Plug 9.0kg
- Dimensions (H x L x W): 200mm x 300mm x 150mm
- Weight: 10.7 kg
Key Features
- Quick Release
- Single piece contacts to prevent hot joints
- Easy termination
- Easy flameproof repair
- Full solid earth connectivity throughout product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone Protection Cover
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Installation and maintenance should be performed by qualified personnel trained in hazardous area electrical equipment to ensure safety and compliance.
Applications
- Mining
- Tunnelling
- Commercial applications
- Group 1 hazardous environments
Standards & Compliance
- Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres
Environmental Benefits
- Durable stainless steel construction reduces need for frequent replacements
- Flameproof repairable design minimizes waste by allowing on-site repairs
Warranty Information
Warranty details available upon request from Ausproof, typically covering manufacturing defects.
Available Now
The Ausproof PL 16 / 25 Crimp & Insul Set 4P (3300) 50 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications.
FAQ
Q: What fault current and high-voltage tolerances does this industrial receptacle support?
A: This rugged assembly is engineered to withstand extreme field faults, passing two phase-through fault tests of 25.0kA for 0.2 seconds and two earth-through fault tests of 8.0kA for 0.2 seconds, with an AC high-voltage phase withstand rating of 8.6kV for one minute.
Q: What accessories are included to protect and install this receptacle body?
A: The unit features a protective silicone cover to shield live connection terminals from site dirt and moisture, and comes with a durable stainless steel hanging plate configured for back-to-back receptacle mounting
