Power Relay Flange Mount 16A 3CO | 24V AC Coil | Pushbutton & Indicator by NHP
Power relay with 16A nominal current and 3 changeover contacts—ideal for industrial automation and commercial HVAC systems. Built for easy installation, with flange mount design and mechanical indicator.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Finder 62 Series Power Relay Flange Mount 16A 3CO 24V AC Coil with Pushbutton plus Mechanical Ind
Brand: NHP
SKU: 6283004024VAC
Alternatively Known As: Power Relay, Flange Mount Relay, 16A Relay
Technical Specifications
- Nominal Current: 16 A
- Nominal Voltage AC: 250 V
- Max Rated Operation Voltage: 400 V
- Rated Switching Power at AC 1: 4000 VA
- Rated Switching Power at AC 15 230 V: 750 VA
- Electrical Life: 100,000 cycles
- Mechanical Life: 30,000,000 cycles
- Operating Temperature: -40 to 70 °C
- Material of Contact: Silver cadmium-oxide
- Drive Polarization: Polarity free
- Dimensions (H x L x W): 35.8mm x 68mm x 38.2mm
- Weight: 0.5 kg
Key Features
- 16A nominal current with 3 changeover contacts.
- Flange mount design for easy installation.
- Mechanical indicator and latching test button included.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, machinery control
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Energy-efficient operation reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Finder 62 Series Power Relay Flange Mount 16A 3CO 24V AC Coil is available now for immediate purchase. Ideal for industrial and commercial applications.
