Premium Hinged Retrofit Collar 80mm | Intumescent Fire Stopping | Easy Retrofit Installation | Corrosion Resistant | by Fire Factory Australia
The Premium Hinged Retrofit Collar 80mm is designed for effective fire stopping of plastic pipes and conduits. Featuring intumescent material that expands under fire conditions, it forms a tight seal to prevent fire spread. With a durable powder-coated finish and a hinged design for easy installation, this collar is perfect for residential, commercial, and industrial applications, ensuring compliance with fire safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Premium Hinged Retrofit Collar 80mm | Intumescent Fire Stopping | Easy Retrofit Installation | Corrosion Resistant | by Fire Factory Australia
Brand: Fire Factory Australia
SKU: FyreCOLLAR-PHRC-80
Alternatively Known As: Fire Collar, Retrofit Fire Collar, Intumescent Pipe Collar, Fire Stopping Collar
Technical Specifications
- Designed for plastic conduits, pipes, and air-conditioning service bundles
- Intumescent material expands under fire conditions to seal penetrations
- Powder-coated finish for corrosion resistance
- Hinged design for easy retrofit installation
- Suitable for pipe sizes from 25mm to 150mm
- Dimensions (H x L x W): 50mm x 100mm x 100mm
- Weight: 1.2 kg
Key Features
- Intumescent fire stopping for plastic pipes, conduits and air-conditioning bundle penetrations
- Actively expands during fire conditions to form a tight seal preventing fire spread
- Fire tested in various wall and floor systems with multiple service types
- Solid hinge and clasp with durable powder-coated finish
- Simple design for quick and easy installation
Professional Installation Requirements
- Installation should be performed by a qualified fire protection professional to ensure compliance and effectiveness.
Applications
- Suitable for plastic pipes and mixed services including electrical conduits, HDPE pipes, PVC pipes, HVAC bundles, insulated pipes and cables
Standards & Compliance
- Complies with AS/NZS 1851 – Routine Service of Fire Protection Systems
Environmental Benefits
- Helps contain fire and smoke, reducing environmental damage during fire incidents
- Durable materials reduce the need for frequent replacements
Warranty Information
5 years warranty against manufacturing defects.
Available Now
The Premium Hinged Retrofit Collar 80mm is available for immediate purchase, ideal for fire protection in residential, commercial, and industrial buildings.
