Primo Single Door Enclosure 1870x670 | IP66 | X15 Finish by B&R Enclosures
Primo single door enclosure with IP66 protection and X15 finish—ideal for industrial and commercial power distribution. Built for durability, with robust construction and compliance with AS/NZS 61439 standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Primo Single door 1870x670 Enclosure, IP66 X15
Brand: B&R Enclosures
SKU: TGBPRM18H06W/RO
Alternatively Known As: Infinity 3G Metering Solution, Primo Power Distribution Unit
Technical Specifications
- Modular Height: 18
- Modular Width: 6
- Materials: Zinc coated steel, aluminium, 316 stainless steel
- Surface Finish: X15 Orange, Light Grey, RAL7035
- Door Type: Single and double door options available
- Dimensions (H x L x W): 1870mm x 480mm x 670mm
- Weight: 50 kg
Key Features
- IP66 protection rating
- Includes AS/NZS 61439 compliance documentation
- Robust construction for long service life
- Available in 6 or 10 module wide sizes
- Low profile door lock with authority key barrel or optional padlockable swing handle
- Open sides for easy baying with side covers available
- Long life, 316 stainless steel hinges
- Large 3mm aluminium gland plate
- Rear rail for cable management according to AS/NZS 3000
- Door stay and A4 document holder supplied as standard
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety and compliance.
Applications
- Power distribution and metering applications up to 630Amps
- Suitable for industrial and commercial environments requiring robust metering solutions
Standards & Compliance
- Complies with AS/NZS 61439 for power distribution equipment.
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Infinity 3G – Primo Range is available now for immediate purchase, ideal for industrial and commercial applications.
