RCBO 10A 30mA 1P C Curve 6kA Chassis Mount Eltech
Eltech RCBO features 10A C curve rating, 30mA sensitivity and 6kA breaking capacity in chassis-mount format. Ideal for switchboard circuit protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: ODN1C1030AS RCBO, Eltech chassis mount RCBO
Technical Specifications
- Rated current: 10 A
- Residual current sensitivity: 30 mA, Type A
- Tripping characteristic: C‑curve (5–10× In)
- Breaking capacity: 6 kA
- Pole configuration: 1 P + N
- Standards: IEC/EN 61009‑1
- Dimensions (H x L x W): 95mm x 17.8mm x 92mm
- Weight: 0.18 kg
Key Features
- Earth‑fault, overload and short‑circuit protection in one device
- Compact chassis‑mount format suitable for switchboard installation
- Type A sensitivity provides protection against AC and pulsating DC leakage currents
- Robust 6 kA breaking capacity for reliable fault interruption
Professional Installation Requirements
- Installation must be performed by a licensed electrician in compliance with AS/NZS 3000 Wiring Rules.
Applications
- Circuit protection in residential, commercial and industrial switchboards
- Residual current and over‑current protection in distribution panels
- Replacement or upgrade of existing RCBO modules in DIN setups
Standards & Compliance
- Complies with AS/NZS 61009 series via IEC/EN 61009‑1 standard for RCBOs
- Installation per AS/NZS 3000 Wiring Rules
Environmental Benefits
- Type A residual current detection enhances electrical safety and reduces risk of fire
- Compact design minimises material use and waste
Warranty Information
Standard manufacturer warranty applies; Eltech offers a 7‑year warranty when installed by a licensed electrician per terms and conditions. Warranty valid on proof of purchase and correct installation.
Available Now
Available through authorised Australian distributors and stockists; visible in Brisbane, Melbourne and Sydney warehouses.
