RCBO 16A 30mA 1P C Curve 6kA Chassis Mount Eltech

BRAND: Eltech
SKU: ODN1C1630AS
$59.00 List price: $78.70
+ −
30 Days Return Electricians Unlock Trade Access
Eltech RCBO features 16A C curve rating, 30mA sensitivity and 6kA breaking capacity in chassis-mount format. Ideal for switchboard circuit protection.

Alternatively Known As: Residual Current Breaker with Overcurrent Protection, RCBO 16A 30 mA C‑Curve

Technical Specifications
  • Rated Current: 16 A
  • Residual Trip Current: 30 mA (Type A)
  • Breaking Capacity: 6 kA (Icn/Ics)
  • Rated Voltage: 230/240 VAC
  • Frequency: 50/60 Hz
  • Residual making & breaking capacity: 3000 A
  • Neutral Fly‑lead Length: 1.4 m
  • Connection Torque: 2.5 Nm
  • Mechanical Endurance: 20 000 cycles
  • Electrical Endurance: 10 000 cycles
  • Operating Temperature: –5 °C to +40 °C
  • Minimum Operating Voltage UB min: 85 V
  • Compliance: IEC 61009‑1
  • Dimensions (H x L x W): 85mm x 18mm x 18mm
  • Weight: 0.18 kg
Key Features
  • Combined overcurrent and residual current protection
  • Compact chassis‑mount design with DIN‑rail installation
  • High 6 kA short‑circuit breaking capacity
  • Neutral fly‑lead ensures uninterrupted neutral connection
  • Robust mechanical performance for frequent operation
Professional Installation Requirements
  • Installation by a licensed electrician in accordance with AS/NZS 3000 (Wiring Rules) and manufacturer’s instructions.
Applications
  • Residential, commercial and industrial switchboard circuit protection
  • Overcurrent and earth‑leakage protection in lighting and power circuits
  • Retrofits and new installations requiring compact DIN‑mount RCBO
Standards & Compliance
  • Complies with IEC 61009‑1; suitable for use in installations designed to AS/NZS 3000 wiring standards
Environmental Benefits
  • Extends system safety and longevity, reducing potential for fire and equipment damage
  • Neutral fly‑lead design promotes product reuse and ease of replacement
Warranty Information

7‑year warranty from Eltech Australia when installed by a licensed electrician per manufacturer’s instructions, valid with proof of purchase.

Available Now

Available from authorised Australian electrical wholesalers and Eltech distribution, subject to stock and location
