RCBO 25A 30mA 1P C Curve 6kA Chassis Mount Eltech

BRAND: Eltech
SKU: ODN1C2530AS
$59.00 List price: $78.70
+ −
30 Days Return Electricians Unlock Trade Access
Eltech RCBO features 25A C curve rating, 30mA sensitivity and 6kA breaking capacity in chassis-mount format. Ideal for switchboard circuit protection.

Alternatively Known As: Residual Current Circuit Breaker with Overcurrent Protection

Technical Specifications
  • Current Rating: 25A
  • Sensitivity: 30mA
  • Poles: 1P + N
  • Tripping Characteristic: C Curve
  • Breaking Capacity: 6kA
  • Mounting Type: Chassis Mount
  • Dimensions (H x L x W): 80mm x 88mm x 18mm
  • Weight: 0.15 kg
Key Features
  • 25A current rating suitable for domestic and commercial use
  • 30mA sensitivity ensuring effective earth leakage protection
  • C Curve tripping for versatile application handling inductive and resistive loads
  • 6kA high breaking capacity for enhanced safety
Professional Installation Requirements
  • Installation should be performed by a licensed electrician.
Applications
  • Switchboard circuit protection
  • Residential circuit protection
  • Commercial circuit protection
Standards & Compliance
  • AS/NZS 61009.1
Environmental Benefits
  • Complies with RoHS standards reducing hazardous substances
Warranty Information

Warranty information available upon request from Eltech.

Available Now

Available through authorised Australian distributors.
