RCBO 32A 30mA 1P C Curve 6kA Chassis Mount Eltech

BRAND: Eltech
SKU: ODN1C3230AS
$59.00 List price: $78.70
+ −
30 Days Return Electricians Unlock Trade Access
Eltech RCBO features 32A C curve rating, 30mA sensitivity and 6kA breaking capacity in chassis-mount format. Ideal for switchboard circuit protection.

Alternatively Known As: Eltech ODN1C3230AS RCBO

Technical Specifications
  • Rated Current: 32 A
  • Tripping Characteristic: C‑curve
  • Residual Current Sensitivity: 30 mA, Type A
  • Breaking Capacity: 6 kA
  • Pole Configuration: 1 pole + neutral, chassis‑mount design
  • Width: 18 mm, with neutral fly‑lead
  • Voltage Rating: 230/240 V, 50 Hz
  • Dimensions (H x L x W): 85mm x 70mm x 18mm
  • Weight: 0.2 kg
Key Features
  • Integrated over‑current and residual current protection
  • Compact chassis‑mount format with neutral fly‑lead
  • C‑curve for handling typical inrush currents
  • Type A detection offers improved protection over Type AC
  • 6 kA breaking capacity suitable for residential and light commercial switchboards
Professional Installation Requirements
  • Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 (Wiring Rules).
Applications
  • Circuit protection in switchboards
  • Residential, commercial and light‑industrial installations needing combined over‑current and earth‑leakage protection
Standards & Compliance
  • Compliant with AS/NZS 3000 for switchboard wiring and electrical safety
Environmental Benefits
  • Compact single‑module design reduces material usage
  • Supports Type A detection, enhancing safety and reducing nuisance trips
Warranty Information

Eltech products come with a 7‑year warranty when installed by a licensed electrician per manufacturer’s instructions, with proof of purchase required. Warranty excludes misuse, modification, or non‑compliant installation. ([eltech.com.au](https://eltech.com.au/wp-content/uploads/2022/07/Terms-and-Conditions-of-Trade-Eltech.pdf?utm_source=openai))

Available Now

Available through authorised Australian distributors; check current stock levels with distributors such as SCHNAP.
