RCBO 45A 10KA 240V 100mA | 2 Module | Earth Leakage & Overload Protection | by Clipsal
The RCBO 45A 10KA 240V 100mA is a reliable residual current circuit breaker designed for residential and commercial switchboards. With a combined RCD and MCB functionality, it offers protection against earth leakage, overload, and short circuits. Ideal for lighting and power circuits, this 2-module unit ensures high performance and compliance with Australian standards, making it a must-have for safe electrical installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 45A 10KA 240V 100mA | 2 Module | Earth Leakage & Overload Protection | by Clipsal
Brand: Clipsal
SKU: SCHA9D12845
Alternatively Known As: 45A RCBO, Clipsal SCHA9D12845, Residual Current Breaker with Overcurrent, 2 Module RCBO, 45A 10kA RCBO
Technical Specifications
- Rated current: 45A
- Breaking capacity: 10kA
- Rated voltage: 240V AC
- Sensitivity: 100mA
- Number of poles: 1P+N (2 module)
- Type: RCBO (Residual Current Circuit Breaker with Overcurrent protection)
- Mounting: DIN rail
- Trip curve: C
- Frequency: 50Hz
- Dimensions (H x L x W): 90mm x 75mm x 36mm
- Weight: 0.25 kg
Key Features
- Combined residual current device (RCD) and miniature circuit breaker (MCB) in one unit
- Rated current: 45A
- Breaking capacity: 10kA
- Rated voltage: 240V AC
- Sensitivity: 100mA
- 2 module width for easy installation
- Provides protection against earth leakage, overload, and short circuit
- High performance and reliability
Professional Installation Requirements
- Must be installed by a licensed electrician in accordance with Australian standards and local regulations.
Applications
- Residential and commercial switchboards
- Protection of final sub-circuits against earth leakage and overload
- Suitable for lighting and power circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 61009 – Residual current operated circuit-breakers with integral overcurrent protection
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty.
Available Now
Available for immediate purchase. Ideal for residential and commercial switchboard applications requiring reliable circuit and earth leakage protection.
