RCBO 4P 6kA C-32A 30mA | High Breaking Capacity | IP2X by Hager
RCBO with 4-pole design and 6kA breaking capacity—ideal for residential and commercial circuit protection. Built for safety with 32A current and 30mA residual current, ensuring reliable performance.
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 4P 6kA C-32A 30mA A
Brand: Hager
SKU: ADM432T
Alternatively Known As: Residual Current Circuit Breaker, RCBO, Circuit Protection Device
- Rated current: 32 A
- Rated residual operating current: 30 mA
- Rated operational voltage: 240 - 415 V
- Rated insulation voltage: 500 V
- Dielectric strength: 2 kV
- Rated impulse withstand voltage: 4000 V
- Ingress Protection (IP) class: IP2X
- Operating temperature: -25 to 40 °C
- Total power loss under IN: 14.60 W
- Dimensions (H x L x W): 84mm x 70mm x 71mm
- Weight: 0.5 kg
- 4-pole design for comprehensive circuit protection.
- Rated current of 32A with a residual current of 30mA.
- High breaking capacity of 6kA.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
- Complies with AS/NZS 3000 for electrical installations.
- RoHS compliant, contributing to reduced environmental impact.
2 years warranty against manufacturing defects.
The Hager RCBO 4P 6kA C-32A 30mA A is available now for immediate purchase. Ideal for residential and commercial electrical safety.
