Residual Current Breaker RCBO 10kA | 63A C Curve | 300mA Type A | DIN Rail by NHP
Residual current breaker RCBO with 10kA breaking capacity and 63A C curve—ideal for residential and commercial electrical safety. Built for enhanced protection with 300mA leakage current and easy DIN rail installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated Current: 63 A
- Rated Voltage: 415 V
- Frequency: 50/60 Hz
- Trip Curve: C
- Rated Impulse Withstand Voltage: 4 kV
- Tripping Time: 300 ms
- Degree of Protection: IP40
- Number of Poles: 4 (3 protected)
- Electrical Life: 10,000 cycles
- Mechanical Life: 20,000 cycles
- Operating Temperature: -5 to 55 °C
- Dimensions (H x L x W): 117.5mm x 77.1mm x 72mm
- Weight: 0.64 kg
Key Features
- 10 kA short circuit breaking capacity
- 300 mA rated leakage current for enhanced safety
- C curve trip characteristic suitable for general applications
- DIN rail mounting for easy installation
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small commercial buildings
- Commercial: Retail spaces and offices requiring electrical safety
Standards & Compliance
- Complies with AS/NZS 61009 for safety and performance standards.
Environmental Benefits
- Enhances electrical safety, reducing the risk of electrical fires and accidents.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The NHP DIN-T Residual Current Breaker RCBO is available now for immediate purchase, ideal for enhancing electrical safety in various applications.
