Residual Current Circuit Breaker 3P+N | 100A 300mA | DIN Rail Type A by NHP

BRAND: NHP

SKU: DSRCD4100300A

$1,024.60 List price: $1,360.60

+ −

30 Days Return Delivery Options

Residual current circuit breaker with 3 pole and neutral design, rated at 100A and 300mA—ideal for residential and commercial safety. Built for easy DIN rail installation, enhancing electrical safety and reducing fire risks.

Description
Attachments

Product Name/Title: NHP DIN-T Residual Current Circuit Breaker RCCB 3Pole and Neutral 100A 300mA Type A ABB Brand F204A

Brand: NHP

SKU: DSRCD4100300A

Alternatively Known As: RCCB, Residual Current Circuit Breaker, RCD, Type A RCCB

Technical Specifications

Number of Poles: 4
Voltage Type: AC
Frequency: 50/60 Hz
Rated Current: 100 A
Leakage Current Type: A
Rated Leakage Current: 300 mA
Min Service Voltage: 205 V
Max Rated Operation Voltage: 455 V
Rated Insulation Voltage: 440 V
Rated Impulse Withstand Voltage: 8 kV
Rated Fault Current: 10000 A
Short Circuit Breaking Capacity: 1 kA
Degree of Protection: IP20
Operating Temperature: 55 °C
Ambient Temperature During Operating: -25-55 °C
Storage Temperature: 70 °C
Pollution Degree: 2
Dimensions (H x L x W): 86mm x 76mm x 72mm
Weight: 0.37 kg

Key Features

3 Pole and Neutral design for enhanced safety.
Rated current of 100A and leakage current of 300mA.
DIN rail mounting for easy installation.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Residential: Homes, apartments, and small buildings
Commercial: Offices, retail spaces, and industrial applications

Standards & Compliance

Complies with AS/NZS 3000 for electrical safety standards.

Environmental Benefits

Enhances electrical safety, reducing the risk of electrical fires and accidents.

Warranty Information

2 years warranty against manufacturing defects.

Available Now

The NHP DIN-T Residual Current Circuit Breaker RCCB 3Pole and Neutral 100A 300mA Type A is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.

DSRCD4100300A-AU-RCCB-3P-and-N-72mm-Datasheet.pdf (DSRCD4100300A-AU-RCCB-3P-and-N-72mm-Datasheet.pdf, 282 Kb) [Download]
