Residual Current Device 6kA 10A | 30mA C Curve | DIN Rail Mount by NHP
Residual current device with 6kA short circuit capacity and 30mA residual current rating—ideal for residential and commercial safety. Built for easy installation on DIN rail, with C curve tripping for reliable protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Residual Current Device Short Body w/ Overcurrent 6kA 10A 1Pole and N C Curve 30mA Type AI
Brand: NHP
SKU: DSRCB1030AI
Alternatively Known As: RCD, RCBO, Residual Current Circuit Breaker, Earth Leakage Circuit Breaker
Technical Specifications
- Rated Current: 10 A
- Rated Voltage: 240 V
- Rated Leakage Current: 30 mA
- Frequency: 50/60 Hz
- Rated Short Circuit Breaking Capacity: 6 kA
- Voltage Type: AC
- Trip Curve: C
- Rated Impulse Withstand Voltage: 6 kV
- Tripping Time: 40 ms
- Min Service Voltage: 117 V
- Max Operating Voltage: 255 V
- Rated Residual Make Break Capacity: 6000 A
- Protected Neutral Pole: Yes
- Number of Poles Total: 2
- Electrical Life: 10000 cycles
- Type of Electric Connection: Fork and pin
- Isolator Application: Yes
- Rated Insulation Voltage: 440 V
- Concurrently Switching Neutral Conductor: Yes
- Mounting Method: DIN rail (top hat rail) 35 mm
- Degree of Protection: IP20
- Number of Protected Poles: 2
- Mechanical Life: 20000 cycles
- Max Shock Duration: 5 ms
- Max Shock Acceleration: 40 g
- Max Vibration Acceleration: 1.5 m/s²
- Max Vibration Frequency Operational: 80 Hz
- Max Vibration Duration: 30 min
- Dimensions (H x L x W): 86mm x 68mm x 36mm
- Weight: 0.25 kg
Key Features
- 6kA short circuit breaking capacity
- 30mA residual current rating
- C curve tripping characteristic
- DIN rail mounting for easy installation
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 61009 for safety and performance standards.
Environmental Benefits
- Enhances electrical safety, reducing the risk of electrical fires and accidents.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Residual Current Device is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
