Residual Current Device RCCB 3 Pole | 63A 100mA | Switched Neutral by NHP
Residual current device RCCB with 3 pole and switched neutral design, rated at 63A and 100mA—ideal for residential and commercial safety. Built for enhanced protection, with DIN rail mounting for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Residual Current Device RCCB 3 Pole and Switched Neutral 63A 100mA Type A
Brand: NHP
SKU: DTRCD463100A
Alternatively Known As: RCCB, Residual Current Circuit Breaker, RCD
Technical Specifications
- Number of Poles: 4
- Voltage Type: AC
- Frequency: 50/60 Hz
- Rated Current: 63 A
- Leakage Current Type: A
- Rated Leakage Current: 100 mA
- Min Service Voltage: 230 V
- Max Rated Operation Voltage: 456 V
- Rated Insulation Voltage: 500 V
- Rated Impulse Withstand Voltage: 4 kV
- Rated Fault Current: 10000 A
- Electrical Life: 10000 cycles
- Surge Current Capacity: 0.25 kA
- Mounting Method: DIN rail
- Degree of Protection: IP40
- Connectable Conductor Cross Section (Solid Core): 1-25 mm²
- Connectable Conductor Cross Section (Multi-Wired): 1-16 mm²
- Operating Temperature: 70 °C
- Ambient Temperature During Operating: -25-70 °C
- Storage Temperature: 70 °C
- Pollution Degree: 2
- Dimensions (H x L x W): 85mm x 75mm x 70mm
- Weight: 0.38 kg
Key Features
- 3 Pole and Switched Neutral design for enhanced safety.
- Rated current of 63A and leakage current of 100mA.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical safety standards.
Environmental Benefits
- Enhances electrical safety, reducing the risk of electrical fires and accidents.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The NHP DIN-T Residual Current Device RCCB 3 Pole and Switched Neutral 63A 100mA Type A is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
