Smart Energy Control Timer MajorTech
MajorTech smart timer features energy control and app scheduling. Ideal for smart home load management and automation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: MTS22 Smart Timer, Wi-Fi DIN Rail Timer, Smart Energy Control Timer
Technical Specifications
- Model: MTS22
- Rated Voltage: 100–240V AC
- Rated Frequency: 50/60Hz
- Rated Current: 30A
- Maximum Resistive Load: 4400W
- Connectivity: Wi-Fi and Bluetooth
- Wi-Fi Network: 802.11 b/g/n, 2.4GHz only
- App: Major Tech Hub
- Timer Modes: Countdown, schedule, circulate, random and inching
- Voice Control: Amazon Alexa and Google Assistant
- Mounting: 35mm DIN rail and Samite/mini rail compatible
- Operating Temperature: -25°C to +55°C
- Relative Humidity: Below 75%
- Approvals: RCM, IEC, ICASA and CE listed by manufacturer
- Dimensions (H x L x W): 86mm x 65mm x 36mm
- Weight: 0.2 kg
Key Features
- Remote monitoring and control through the Major Tech Hub app
- Historical and real-time energy usage information
- Flexible countdown, schedule, circulate, random and inching timer functions
- Dual Wi-Fi and Bluetooth connectivity
- Compatible with 2.4GHz Wi-Fi networks
- Voice control integration with Alexa and Google Assistant
- Child-lock function to help prevent accidental manual switching
- Compact DIN rail and mini-rail mounting design
- Suitable for high-current resistive load control up to 30A
Professional Installation Requirements
- This is a mains-connected DIN rail device. Installation and wiring should be performed by a licensed electrician in accordance with the manufacturer's wiring instructions and applicable Australian electrical installation rules, including AS/NZS 3000.
Applications
- Smart home load management
- Scheduled control of lighting and electrical appliances
- Automated control of pumps, heating equipment and other resistive loads
- Residential, commercial and light industrial distribution boards
- Energy monitoring and demand-control applications
Standards & Compliance
- AS 60669.2.1:2020 listed in the manufacturer's manual for the switching device
- RCM approval stated by the manufacturer for the Australian market
- Installation to be carried out in accordance with AS/NZS 3000 wiring rules
Environmental Benefits
- Supports energy reduction by scheduling equipment to operate only when required
- Provides energy usage data to help identify avoidable consumption
- Enables automated load management that can reduce unnecessary standby and operating time
- Compact, durable construction may reduce replacement frequency and material waste
Warranty Information
Major Tech provides a 2-year warranty for timers and smart products, subject to the manufacturer's warranty terms, proof of purchase and exclusions for misuse, electrical surges, unauthorised alterations and inadequate care.
Available Now
Available through Major Tech and authorised Australian electrical distributors.
