Stainless Steel Enclosure 20Hx6W | IP66 Rated | Secure Locking | N4 Finish by B&R Enclosures
Stainless steel enclosure with IP66 rating and secure 3-point locking—ideal for power distribution in harsh environments. Built for durability, with N4 finish and easy baying for seamless integration.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Primo Single door 20Hx6W Stainless Encl. IP66
Brand: B&R Enclosures
SKU: TGBPRM20H06W/S
Alternatively Known As: Infinity 3G Metering Solution, Primo Power Distribution Unit
Technical Specifications
- Modular Height: 20
- Modular Width: 6
- Materials: 316 stainless steel, zinc coated steel, aluminium
- Surface Finish: N4 surface finish
- Height: 2070mm
- Width: 670mm
- Depth: 480mm
- Dimensions (H x L x W): 2070mm x 480mm x 670mm
- Weight: 50 kg
Key Features
- IP66 protection rating for outdoor and harsh environments.
- Robust construction for long service life.
- Available in 6 or 10 module wide sizes.
- Low profile door lock with secure 3 point locking system.
- Open sides for easy baying with optional side covers.
- Long life, 316 stainless steel hinges.
- Large 3mm aluminium gland plate.
- Rear rail for cable management according to AS/NZS 3000.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety and compliance.
Applications
- Power distribution and metering applications in commercial and industrial settings.
Standards & Compliance
- Complies with AS/NZS 61439 for low voltage switchgear and controlgear assemblies.
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Infinity 3G – Primo Range is available now for immediate purchase. Ideal for power distribution and metering applications in various environments.
