Surface Switch 1 Gang 3 Pole | 500VAC 10A | IP66 Rated | Resistant Orange by Clipsal
Surface switch with 3-pole rotary control and 500VAC 10A rating—ideal for small commercial utility industry. Built for durability, with IP66 protection and resistant orange finish.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Clipsal - 56 Series, Surface Switch, 1 Gang, 3 Pole, 500VAC, 10A - Resistant Orange
Brand: Clipsal
SKU: 56SW310-RO
Alternatively Known As: Clipsal 56 Series Switch, 3 Pole Surface Switch, Rotary Switch
Technical Specifications
- Rated operational voltage: 500 V AC 50 Hz
- Rated current: 10 A
- Material: Polycarbonate
- Breaking capacity: 10 kA
- Rated short-circuit making capacity: 1 kA
- Rated impulse withstand voltage: 4 kV
- Ambient air temperature for operation: -25...75 °C
- Dimensions (H x L x W): 107mm x 108mm x 101mm
- Weight: 0.6 kg
Key Features
- 3-pole switch with rotary knob control
- IP66 rated for protection against dust and water
- Suitable for surface mounting
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Small commercial utility industry
Standards & Compliance
- Complies with AS/NZS 3133 and AS 60529 for safety and performance standards.
Environmental Benefits
- Compliant with RoHS directives and regulations.
Warranty Information
Standard warranty applies.
Available Now
The Clipsal 56 Series Surface Switch 1 Gang 3 Pole 500VAC 10A is available now for immediate purchase. Ideal for small commercial and industrial applications.
