Surge Protection Device 1P Type 2 275V 20kA Grey Hager

BRAND: :hager
SKU: SPB140R
$176.40 List price: $219.80
+ −
30 Days Return Electricians Unlock Trade Access
Hager Surge Protection Device 1P Type 2 275V 20kA Grey features 1-Pole, Type 2, 20kA discharge, 275V. Ideal for domestic switchboards.
Technical Specifications
  • Rated operational voltage Ue: 240 - 415 V
  • Continuous operating voltage Uc: 275 V
  • Voltage protection level Up: 1.35 kV
  • Nominal discharge current In: 20 kA
  • Max. overcurrent protection device: 125 A
  • Operating temperature: -40 - 80 °C
  • Network type: TN, TT
  • Frequency: 50 - 60 Hz
  • Dimensions (H x L x W): 97mm x 58mm x 18mm
  • Weight: 0.5 kg
Key Features
  • Nominal discharge current of 20 kA.
  • Maximum discharge current (Imax) of 40 kA.
  • Remote signaling contact for monitoring.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, offices
  • Commercial: Retail, hospitality, workspaces
  • General: Any installation requiring surge protection
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
  • RoHS compliant, reducing hazardous substances in electrical equipment.
  • Halogen-free materials contribute to safer disposal and recycling.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager Surge Protection Device 1P T2 TNC Uc 275V is available now for immediate purchase. Ideal for residential and commercial electrical systems requiring surge protection.

Data Sheet (SPB140R, 93 Kb) [Download]

Certificate (PEP_HAGER_HAGE_00444_V01.01_EN_27082021.pdf, 231 Kb) [Download]

Certificate (reach_declaration_SPB140R.pdf, 103 Kb) [Download]

Certificate (rohs_declaration_SPB140R.pdf, 104 Kb) [Download]

Data Sheet (SPB140R.webp, 162 Kb) [Download]

Certificate (ID1_SPBXXXD_R_6LE007690AB.pdf, 911 Kb) [Download]

Certificate (SURGE_BROCHURE_AUS_LOWRES.pdf, 934 Kb) [Download]

Certificate (DECLARATION_21_2979_07_21.pdf, 306 Kb) [Download]
