Through beam Photoelectric switch WS12-3D2430 emitter redlight, M12 plug
The SICK WS12-3D2430 Through Beam Photoelectric Switch features a visible red LED emitter with a sensing range up to 15 meters, designed for reliable object detection in industrial automation with robust IP66-69K rated metal housing.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Through beam Photoelectric switch WS12-3D2430 emitter redlight, M12 plug
Brand: SICK
SKU: 2041879
Alternatively Known As: Photoelectric sensor, Through-beam sensor, Optical sensor, Photo sensor emitter, Industrial photoelectric switch
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 m to 15 m (max 20 m)
- Light source: LED, visible red light, wavelength 640 nm
- Light spot size at 15 m: Ø 220 mm
- Adjustment: Potentiometer, 5 turns
- Angle of dispersion: Approx. 1.5°
- Supply voltage: 10 V DC to 30 V DC
- Current consumption sender: ≤ 30 mA
- Current consumption receiver: ≤ 15 mA
- Protection class: III
- Output type: PNP, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 330 µs
- Switching frequency: 1500 Hz
- Housing material: Metal
- Front screen material: Plastic, PMMA
- Connection: Male M12, 4-pin
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- Dimensions (H x L x W): 49mm x 42mm x 16mm
- Weight: 0.12 kg
Key Features
- Through-beam photoelectric sensor with visible red LED light
- Sensing range up to 15 meters, max 20 meters
- Potentiometer adjustment with 5 turns for sensitivity tuning
- High switching frequency of 1500 Hz and fast response time ≤ 330 µs
- Robust metal housing with IP66, IP67, and IP69K protection ratings
- Operating temperature range from -40°C to +60°C
- M12 4-pin male connector for easy installation
- Complementary PNP output with light/dark switching mode
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with industrial sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Safety and monitoring in manufacturing lines
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with efficient LED light source
- Durable metal housing reduces waste through extended product life
- Complies with China RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK Through Beam Photoelectric Switch WS12-3D2430 is available for immediate purchase, ideal for industrial automation and safety applications.
