Unmanaged Ethernet Switch 8-Port | 10/100 Mbps | Compact DIN Rail Mount | IP20 by Allen-Bradley
Unmanaged Ethernet switch with 8 ports supporting 10/100 Mbps—ideal for industrial automation networks. Built for small to medium-sized segments, with a compact DIN rail mount design and low power consumption.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Unmanaged Ethernet Switch 8-Port | 10/100 Mbps | Compact DIN Rail Mount | IP20 by Allen-Bradley
Brand: Allen-Bradley
SKU: 1783-US8T
Alternatively Known As: Stratix 2000 8-Port Ethernet Switch, Allen-Bradley 1783-US8T Switch, Industrial Unmanaged Ethernet Switch
Technical Specifications
- Ports per Module: 8
- Copper Ports: 8 x 10/100 Full/Half Duplex, Autonegotiate
- Power Requirements: 20V AC / 24V DC
- Input Power Range: 10-24V AC, 10-35V DC
- Inrush Current, Max: 2.2A
- Power Consumption, Max: 4 W (6VA)
- Current: 400 mA at 10V DC Max
- Enclosure Type Rating: IP20
- Mounting: DIN Rail
- Dimensions (H x L x W): 70mm x 120mm x 100mm
- Weight: 0.5 kg
Key Features
- 8 copper ports supporting 10/100 Mbps full/half duplex with autonegotiation
- Compact DIN rail mountable enclosure
- Low power consumption of 4 W (6VA) max
- IP20 rated enclosure for protection against solid objects
Professional Installation Requirements
- Installation by a qualified network technician or electrician is recommended to ensure proper mounting, power supply connection, and network configuration.
Applications
- Industrial automation networks
- Factory floor Ethernet connectivity
- Small to medium-sized network segments requiring unmanaged switches
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption reduces energy usage and operational costs
- Durable design minimizes replacement frequency and electronic waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Allen-Bradley for specific warranty details.
Available Now
This product available now for immediate purchase.
