UV LED Light Sensor LUT8U-11201 | 375 nm Wavelength | IP67 Rated | by SICK
The UV LED Light Sensor LUT8U-11201 features a 375 nm wavelength and manual rotary switch adjustment, making it ideal for industrial automation and quality control applications. With a high switching frequency of 2.5 kHz and an IP67 rated enclosure, this sensor ensures reliable performance in demanding environments, providing accurate UV light sensing for production lines.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: UV LED Light Sensor LUT8U-11201 | 375 nm Wavelength | IP67 Rated | by SICK
Brand: SICK
SKU: 1047042
Alternatively Known As: UV LED Sensor, UV Light Sensor, SICK LUT8U Sensor, Industrial UV Sensor
Technical Specifications
- Sensing distance: ≤ 20 mm
- Working range: 10 mm to 40 mm
- Light source: LED, UV
- Wavelength: 375 nm
- Light emission: Long side
- Light spot size: 3 mm x 9 mm
- Light spot direction: Vertical
- Receiving filters: ≤ 420 nm
- Receiving range: 450 nm to 750 nm
- Adjustment: Manual (rotary switch)
- Output function: Light switching
- Supply voltage: 12 V DC to 30 V DC
- Ripple: < 5 V pp
- Current consumption: < 100 mA
- Switching frequency: 2.5 kHz
- Response time: 200 µs
- Switching output: PNP, NPN
- Output current max: 100 mA
- Connection type: Male connector M12, 5-pin
- Protection class: II
- Circuit protection: Reverse polarity, short-circuit, interference pulse suppression
- Enclosure rating: IP67
- Housing material: Zinc diecast
- Operating temperature: -10 °C to +55 °C
- Storage temperature: -25 °C to +75 °C
- Shock load: According to IEC 60068
- Dimensions (H x L x W): 53mm x 80mm x 30.4mm
- Weight: 0.4 kg
Key Features
- UV LED light source with 375 nm wavelength
- Manual rotary switch adjustment
- Light switching output function
- High switching frequency of 2.5 kHz
- IP67 rated enclosure for dust and water protection
- Reverse polarity and short-circuit protected
- Male connector M12, 5-pin connection
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation for object detection
- Quality control in manufacturing
- UV light sensing in production lines
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Low power consumption with supply voltage from 12 V DC to 30 V DC
- Durable zinc diecast housing extends product life reducing waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK LUT8U-11201 UV LED Light Sensor is available for immediate purchase, ideal for industrial automation and quality control applications.
