VLR-263RL3911 | Reflectors and optics
The SICK VLR-263RL3911 is a LED ring light reflector designed for industrial illumination applications, featuring a red 630 nm LED light source with low risk classification and robust connectivity.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: VLR-263RL3911 | Reflectors and optics
Brand: SICK
SKU: 2118267
Alternatively Known As: LED Ring Light, Red LED Illuminator, SICK Reflector Light
Technical Specifications
- Light source: LED, red, 630 nm
- LED class: Risk group 1 (low risk, IEC62471:2008)
- Supply voltage: 24 V DC
- Power consumption: 0.23 A
- Connections: Connector M12, 4-pin, cable length 0.5 m
- Ambient operating temperature: 0°C to +40°C
- Storage temperature: -20°C to +60°C
- Dimensions (H x L x W): 30mm x 100mm x 100mm
- Weight: 0.2 kg
Key Features
- LED red light source at 630 nm wavelength
- Low risk LED class (Risk group 1, IEC62471:2008)
- 24 V DC supply voltage
- Power consumption of 0.23 A
- Connector M12, 4-pin with 0.5 m cable length
- Operating temperature range 0°C to +40°C
- Storage temperature range -20°C to +60°C
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure proper electrical connection and safety compliance.
Applications
- Industrial automation lighting
- Machine vision illumination
- Inspection systems requiring red LED lighting
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Energy-efficient LED technology reduces power consumption.
- Long LED lifespan minimizes waste and replacement frequency.
Warranty Information
Standard manufacturer warranty applies, typically 1 year against defects.
Available Now
The SICK VLR-263RL3911 LED Ring Light Reflector is available for immediate purchase, ideal for industrial and machine vision lighting applications.
