WL12L-2B530S03 | Photoelectric sensors
The SICK WL12L-2B530S03 is a high-performance photoelectric retro-reflective sensor designed for precise detection of small and fast-moving objects in industrial environments, featuring robust metal housing and advanced laser technology.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: WL12L-2B530S03 | Photoelectric sensors
Brand: SICK
SKU: 1019615
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, Laser sensor, Industrial photo sensor, SICK sensor WL12L
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor without reflector minimum distance
- Sensing range max.: 0 m to 18 m
- Light source: Laser, visible red light, wavelength 650 nm
- Light spot size: Ø 0.8 mm at 300 mm distance
- Laser class: 2 according to EN 60825-1:2014 and IEC 60825-1:2007
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 55 mA
- Output type: PNP and NPN selectable
- Switching modes: Light switching and dark switching selectable
- Output current max: ≤ 100 mA
- Response time: ≤ 200 µs
- Switching frequency: 2,500 Hz
- Protection class: III
- Circuit protection: Types A, C, D
- Housing material: Metal with plastic PMMA front screen
- Connection: M12, 5-pin plug
- Enclosure rating: IP67 and IP69K
- Operating temperature: -10 °C to +50 °C
- Storage temperature: -25 °C to +75 °C
- Dimensions (H x L x W): 49mm x 42mm x 15mm
- Weight: 0.13 kg
Key Features
- Photoelectric retro-reflective sensor with autocollimation/coaxial optics
- Sensing range up to 18 meters without reflector
- Polarisation filter included
- Visible red laser light source with 650 nm wavelength
- Fixed focus adjustment and fixed sensitivity control
- Selectable light/dark switching modes via control cable
- High switching frequency of 2,500 Hz and fast response time ≤ 200 µs
- Robust metal housing with IP67 and IP69K protection ratings
- Connection via M12, 5-pin plug
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper setup and compliance with safety standards.
Applications
- Detecting small objects
- Detection of objects moving at high speeds
- Industrial automation and safety systems
- Material handling and packaging lines
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Energy-efficient laser technology reduces power consumption
- Durable metal housing extends product lifespan, reducing waste
- Complies with China RoHS for hazardous substance reduction
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK WL12L-2B530S03 Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
