WT24-2B440T01 | Photoelectric sensors
The SICK WT24-2B440T01 is a robust photoelectric proximity sensor featuring background suppression, a wide sensing range up to 1200 mm, and a durable Teflon-coated metal housing, ideal for industrial automation and safety applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: WT24-2B440T01 | Photoelectric sensors
Brand: SICK
SKU: 1017911
Alternatively Known As: Photoelectric proximity sensor, Background suppression sensor, Industrial photo sensor, SICK proximity sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 100 mm to 1200 mm
- Light source: Visible red LED
- Light spot size: Ø 40 mm at 1200 mm distance
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 50 mA
- Switching output: NPN or PNP selectable
- Switching mode: Light/dark switching selectable
- Output current max: ≤ 100 mA
- Response time: ≤ 500 µs
- Switching frequency: 1000 Hz
- Connection type: Male M12, 4-pin connector
- Circuit protection: Types A, C, D
- Protection class: Class II
- Enclosure rating: IP67
- Ambient operating temperature: -40 °C to +60 °C
- Housing material: Metal zinc diecast with PTFE coating
- Dimensions (H x L x W): 87.5mm x 65mm x 27mm
- Weight: 0.35 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Rectangular metal housing with PTFE (Teflon) coating for durability
- Sensing range from 100 mm to 1200 mm
- Visible red LED light source with Ø 40 mm light spot at 1200 mm
- Selectable switching mode: light/dark switching
- Selectable output type: NPN or PNP
- High switching frequency of 1000 Hz and fast response time ≤ 500 µs
- IP67 rated enclosure for dust and water protection
- Wide ambient operating temperature range from -40 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with industrial sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Material handling and packaging systems
- Safety and monitoring in manufacturing processes
- Robotics and conveyor systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable PTFE-coated housing extends product lifespan, reducing waste
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WT24-2B440T01 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
