Central Vacuum Motor 2HP Valet

BRAND: Ness
SKU: VAC-212
$1,057.00 List price: $1,409.40
+ −
30 Days Return Electricians Unlock Trade Access
Valet central vacuum motor features 2HP power output. Ideal for central vacuum power units.

Alternatively Known As: Valet 2HP Ducted Vacuum Motor, Ametek 115684 Vacuum Motor, Central Vacuum Power Unit Motor

Technical Specifications
  • Motor Power: 2HP nominal
  • Motor Type: Two-stage tangential bypass
  • Voltage: 240V AC
  • Frequency: 50/60Hz
  • Maximum Input: Approximately 1,250W
  • Maximum Current: Approximately 5.9A
  • Motor Diameter: 183mm
  • Compatibility: Valet V2P, V150, V250, V350, VL200 and VB150 power units
  • Bearings: Double ball bearings
  • Discharge: Tangential bypass
  • Grounding: Provision for grounding
  • Dimensions (H x L x W): 155mm x 183mm x 183mm
  • Weight: 4 kg
Key Features
  • Replacement motor for selected Valet central vacuum power units
  • Two-stage design for high vacuum performance
  • Suitable for 240V Australian electrical supply
  • Single-speed motor with sealed bearing construction
  • Compatible with selected Valet and equivalent ducted vacuum systems
  • Designed for clean, dry, filtered air applications
Professional Installation Requirements
  • Installation must be performed by a qualified electrician. Confirm motor compatibility, wiring, seals and mounting before installation. Incorrect installation may damage the motor or void the warranty.
Applications
  • Replacement of failed motors in Valet central vacuum power units
  • Servicing ducted vacuum systems in residential properties
  • Repair of compatible Valet V2P, V150, V250, V350, VL200 and VB150 units
Standards & Compliance
  • AS/NZS 60335.2.2 for household and similar vacuum cleaners, including centrally-sited vacuum cleaners, applicable to the completed appliance and installation
Environmental Benefits
  • Extends the service life of an existing central vacuum power unit and reduces replacement waste
  • Replacement of the motor avoids disposal of the complete power unit when the remaining components are serviceable
  • Double ball-bearing construction supports a longer operating life when correctly installed and maintained
Warranty Information

12-month warranty from date of purchase for Valet spare motors. Valet central vacuum power-unit warranties are separate and do not automatically apply to replacement motors.

Available Now

Available through Valet and authorised Australian distributors.
