Central Vacuum Motor to Suit V1SU and V2.2 Ametek Valet
Valet central vacuum motor to Suit V1SU and V2.2 power units. Ideal for central vacuum power units.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Valet VAC-325 Motor, Ametek Lamb 122286 Vacuum Motor, Central Vacuum Replacement Motor
Technical Specifications
- Manufacturer Motor Model: Ametek 122286
- Valet Part Number: VAC-325
- Compatibility: Valet V1SU and V2.2 power units; VAC-128 and VAC-002
- Motor Type: Universal AC motor, two-stage, single-speed
- Discharge Type: Thru-flow
- Rated Voltage: 230 V AC, 50/60 Hz
- Motor Diameter: 145 mm nominal
- Peak Current: Approximately 7.6 A when used in compatible Valet power units
- Airflow: Up to approximately 132.7 CFM in the compatible V1SU/V2.2 power-unit configuration
- Bearing Type: Double ball bearings
- Thermal Protection: Integrated thermal device
- Air Requirement: Clean, dry and filtered air only
- Dimensions (H x L x W): 163mm x 163mm x 145mm
- Weight: 3.5 kg
Key Features
- Genuine replacement motor for specified Valet central vacuum power units
- Suitable for Valet V1SU and V2.2 systems
- Two-stage thru-flow design for central vacuum applications
- Double ball bearings for motor support and service life
- Integrated thermal protection
- Designed as a direct replacement for the Ametek 122286 motor assembly
- Incorrect wiring or installation may damage the motor and void warranty
Professional Installation Requirements
- Installation must be performed by a qualified electrician or suitably experienced central-vacuum technician. Isolate mains power before removal, verify motor compatibility, use the correct seal or gasket where required, and avoid overtightening mounting bolts.
Applications
- Replacement of failed motors in Valet V1SU central vacuum power units
- Replacement of failed motors in Valet V2.2 central vacuum power units
- Domestic central vacuum system repairs and refurbishment
- Servicing compatible Valet VAC-128 and VAC-002 power units
Standards & Compliance
- AS/NZS 60335.2.69:2017 is the relevant safety-standard reference for motor-operated vacuum cleaners; confirm certification of the complete installed Valet power unit rather than treating this replacement motor alone as independently certified
- Electrical installation should comply with AS/NZS 3000 Wiring Rules where applicable
Environmental Benefits
- Extends the service life of an existing central vacuum power unit and reduces replacement of the complete appliance
- Supports repair and reuse of existing equipment, reducing component and e-waste
- Thru-flow motor design is intended for clean, dry and filtered air, helping protect the motor from premature contamination-related failure
Warranty Information
One-year parts warranty for Valet and iCentral central vacuum replacement motors, excluding labour. Incorrect installation, misuse or unauthorised servicing may affect warranty coverage.
Available Now
Available through Valet, Ness Corporation and authorised Australian distributors, subject to current stock availability.
