Distribution Board 24 Poles | 160A Main Switch | IP56 Weatherproof | Grey by Clipsal

BRAND: Clipsal
SKU: MD224CM1
$2,943.30 List price: $4,415.00
Free pick up (over 25 kg)
For delivery quote message
Distribution board with 24 poles and a 160A main switch—ideal for residential and commercial applications. Built for durability, with IP56 weatherproof protection and a compact grey design.

Product Name/Title: Acti9, MD Isobar standard distribution board, 24 poles, 160A main switch, 18mm, IP56, grey

Brand: Clipsal

SKU: MD224CM1

Alternatively Known As: Acti9 Distribution Board, MD Isobar DB, Clipsal Distribution Board

Technical Specifications
  • Rated operational voltage: 415 V
  • Rated operational current: 160 A
  • Breaking capacity: 25 kA
  • Rated insulation voltage: 500 V
  • Rated impulse withstand voltage: 6 kV
  • Enclosure material: Steel
  • Network frequency: 50 Hz
  • Poles description: 3P + N
  • Dimensions (H x L x W): 750mm x 225mm x 580mm
  • Weight: 42 kg
Key Features
  • 24 poles with a 160A main switch
  • IP56 rated for weatherproof protection
  • Includes earth/neutral terminal block and removable gland plates
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
  • Complies with relevant Australian standards for electrical safety.
Environmental Benefits
  • Compliant with EU RoHS directive and free of toxic heavy metals.
Warranty Information

Standard warranty as per manufacturer guidelines.

Available Now

The Clipsal Acti9 MD Isobar Standard Distribution Board is available now for immediate purchase. Ideal for residential and commercial power distribution needs.

MD224CM1 (MD224CM1, 209 Kb) [Download]
