Double Pole Switched Socket 10A 250V AC ON OFF Rocker Switch White Clipsal
The Double Pole Switched Socket provides a 10A, 250V AC power outlet with an ON/OFF rocker switch for residential, commercial and light industrial applications. It features a 2-pole configuration, 3 pins and a 45mm mounting centre. The socket has a white electric finish with screw terminal connections for secure wiring. See the technical specifications and installation requirements below before ordering.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Double Pole Switched Socket | 10A 250V AC | ON/OFF Rocker Switch | White Electric Finish | @1 | by Clipsal
Brand: Clipsal
SKU: MEDML/ABC15DMWE
Alternatively Known As: Double Pole Switched Socket, GPO Switched Outlet, Clipsal 10A Socket, Single Switched Power Point, MEDML/ABC15DMWE
Technical Specifications
- Rated Voltage: 250V AC
- Rated Current: 10A
- Frequency: 50Hz
- Poles: 2 (Double Pole)
- Pins: 3
- Switch Type: ON/OFF Rocker
- Mounting Method: Panel
- Mounting Centres: 45mm
- Connection: Screw terminals
- Orientation: Horizontal
- Finish: White Electric
- Dimensions (H x L x W): 74mm x 45mm x 45mm
- Weight: 0.12 kg
Key Features
- Double pole switched socket for enhanced safety
- 10A, 250V AC rating suitable for standard Australian power requirements
- 1 gang, 3 pin configuration
- ON/OFF rocker switch for easy operation
- Panel mounting with 45mm mounting centres
- Screw connection terminals for secure wiring
- Horizontal orientation
- Durable white electric finish
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with Australian wiring rules and standards.
Applications
- Residential: Homes, apartments, and units for general power outlet needs
- Commercial: Offices, retail stores, and hospitality venues
- Industrial: Workshops and light industrial environments requiring reliable switched power
Standards & Compliance
- Complies with AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Long-lasting, durable construction reduces replacement frequency and waste
- Reliable electrical connections help prevent energy loss and improve safety
Warranty Information
Clipsal provides a 2-year warranty against manufacturing defects for this product.
Available Now
The Clipsal MEDML/ABC15DMWE Double Pole Switched Socket Outlet is available for immediate purchase. Ideal for residential, commercial, and light industrial power outlet applications.
FAQ
Q: What is the rating of the Double Pole Switched Socket?
A: The socket is rated at 250V AC and 10A, with a 2-pole configuration and 3 pins.
Q: Where can this Double Pole Switched Socket be used?
A: It is listed for residential, commercial and light industrial power outlet applications.
Pair this socket with a double pole switch mechanism for compatible switching applications.
For overhead control applications, consider a ceiling pull switch alongside the switched socket.
For kitchen installations, a cooker switch can provide a dedicated switching option for appliances.
Review the switch amp rating guide when checking the current rating requirements for switch installations.
