Acti9, MD Encapsulated distribution board, 24 poles, 160A main switch, 18mm, IP56, grey

Encapsulated Distribution Board 24 Poles | 160A Main Switch | IP56 Weatherproof | Grey by Clipsal

BRAND: Clipsal

SKU: MD224C31

$2,091.20 List price: $3,136.80

Free pick up (over 25 kg)

For delivery quote message

30 Days Return Delivery Options

Encapsulated distribution board with 24 poles and 160A main switch—ideal for residential and commercial use. Built for robust electrical distribution, with IP56 weatherproof rating for outdoor installations.

Description
Attachments

Product Name/Title: Acti9, MD Encapsulated distribution board, 24 poles, 160A main switch, 18mm, IP56, grey

Brand: Clipsal

SKU: MD224C31

Alternatively Known As: MD Encapsulated DB, Acti9 Distribution Board

Technical Specifications

Rated operational voltage: 415 V
Rated operational current: 160 A
Breaking capacity: 25 kA
Rated insulation voltage: 500 V
Rated impulse withstand voltage: 6 kV
Enclosure material: Steel
Enclosure type: Weatherproof
Network frequency: 50 Hz
Dimensions (H x L x W): 750mm x 225mm x 580mm
Weight: 36 kg

Key Features

24 poles with a 160A main switch for robust distribution.
IP56 rated for protection against dust and water ingress.
Weatherproof enclosure suitable for outdoor installations.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Residential: Homes, apartments, and small buildings
Commercial: Offices, retail spaces, and industrial applications

Standards & Compliance

Complies with relevant Australian standards for electrical safety.

Environmental Benefits

Compliant with EU RoHS directive, ensuring reduced environmental impact.

Warranty Information

Standard warranty as per manufacturer guidelines.

Available Now

The Clipsal Acti9 MD Encapsulated Distribution Board is available now for immediate purchase. Ideal for residential and commercial electrical distribution needs.

MD224C31 (MD224C31, 210 Kb) [Download]
