Home/Electrical/Switchboards/Distribution Boards/Encapsulated Distribution Board 36 Poles | 250A | IP42 Rated | Grey by Clipsal

Trade Discount 33%

Acti9, MB Encapsulated distribution board, 36 poles, 250A no main switch, 18mm, IP42, grey

Encapsulated Distribution Board 36 Poles | 250A | IP42 Rated | Grey by Clipsal

BRAND: Clipsal

SKU: MB236C30

$1,198.60 List price: $1,797.80

Free pick up (over 25 kg)

For delivery quote message

30 Days Return Delivery Options

Encapsulated distribution board with 36 poles and 250A rating—ideal for industrial and commercial facilities. Built for robust electrical distribution, with IP42 protection and a sleek grey finish.

Description
Attachments

Product Name/Title: Acti9, MB Encapsulated distribution board, 36 poles, 250A no main switch, 18mm, IP42, grey

Brand: Clipsal

SKU: MB236C30

Alternatively Known As: Acti9 Distribution Board, Encapsulated DB, 36 Pole Distribution Board

Technical Specifications

Rated operational voltage: 415 V
Rated operational current: 250 A
Breaking capacity: 25 kA
Rated insulation voltage: 500 V
Rated impulse withstand voltage: 6 kV
Enclosure material: Steel
Enclosure type: Standard
Door type: External plain
Network frequency: 50 Hz
Poles description: 3P + N
Dimensions (H x L x W): 750mm x 235mm x 580mm
Weight: 32.8 kg

Key Features

36 poles with a 250A rating, designed for efficient distribution.
IP42 rated for protection against solid objects and water.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Commercial: Industrial facilities, large buildings
General: Any application requiring a robust distribution board

Standards & Compliance

Complies with relevant Australian standards for electrical distribution.

Environmental Benefits

Packaging made with recycled cardboard.

Warranty Information

Standard warranty applies, please check with the manufacturer for details.

Available Now

The Clipsal Acti9 Encapsulated Distribution Board is available now for immediate purchase. Ideal for commercial and industrial applications.

MB236C30 (MB236C30, 188 Kb) [Download]
