Encapsulated Distribution Board 36 Poles | 250A | IP56 Weatherproof | Grey by Clipsal
Encapsulated distribution board with 36 poles and 250A capacity—ideal for industrial and commercial applications. Built for robust electrical distribution, with IP56 weatherproof rating and durable steel enclosure.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Acti9, MD Encapsulated distribution board, 36 poles, 250A no main switch, 18mm, IP56, grey
Brand: Clipsal
SKU: MD236D30
Alternatively Known As: Acti9 Distribution Board, Encapsulated DB, 250A Distribution Board
Technical Specifications
- Rated operational voltage: 415 V
- Rated operational current: 250 A
- Breaking capacity: 25 kA
- Rated insulation voltage: 500 V
- Rated impulse withstand voltage: 6 kV
- Enclosure type: Weatherproof enclosure
- Enclosure material: Steel
- Network frequency: 50 Hz
- Poles description: 3P + N
- Dimensions (H x L x W): 1000mm x 225mm x 580mm
- Weight: 41 kg
Key Features
- IP56 rated for protection against dust and water.
- 36 poles for extensive circuit management.
- Weatherproof enclosure suitable for outdoor installations.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Commercial: Industrial facilities, large buildings requiring robust electrical distribution.
- General: Any application needing a reliable and weatherproof distribution board.
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Packaging made with recycled cardboard.
Warranty Information
Standard warranty terms apply, please check with the manufacturer.
Available Now
The Clipsal Acti9 MD Encapsulated Distribution Board is available now for immediate purchase. Ideal for commercial and industrial applications requiring reliable electrical distribution.
