Trade Discount 33%
Encapsulated Distribution Board 60 Poles | 160A Main Switch | IP42 Grey by Clipsal
Encapsulated distribution board with 60 poles and 160A main switch—ideal for commercial and industrial facilities. Built for robust electrical distribution, with IP42 protection and steel enclosure.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Acti9, MB Encapsulated distribution board, 60 poles, 160A main switch, 18mm, IP42, grey
Brand: Clipsal
SKU: MB260E31
Alternatively Known As: Acti9 Distribution Board, Encapsulated DB, Circuit Protection Board
Technical Specifications
- Rated operational voltage: 415 V
- Rated operational current: 160 A
- Breaking capacity: 25 kA
- Rated insulation voltage: 500 V
- Rated impulse withstand voltage: 6 kV
- Enclosure material: Steel
- Network frequency: 50 Hz
- Enclosure type: Standard
- Door type: External plain
- Dimensions (H x L x W): 1200mm x 235mm x 580mm
- Weight: 41 kg
Key Features
- 60 poles with a 160A main switch for extensive circuit management.
- IP42 rated for protection against solid objects and water.
- Includes removable gland plates and a circuit schedule card.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Commercial: Industrial facilities, large buildings
- General: Any application requiring robust electrical distribution
Standards & Compliance
- Pro-active compliance with EU RoHS directive.
Environmental Benefits
- Free of substances of very high concern and toxic heavy metals.
Warranty Information
Standard warranty applies, please check with the manufacturer for details.
Available Now
The Clipsal Acti9 Encapsulated Distribution Board is available now for immediate purchase. Ideal for commercial and industrial applications.
