Extended Battery Enclosure E-Type Cabinet | 20 x 280W Batteries | Free Standing Black Finish | Eaton
The Eaton Extended Battery Enclosure E-type Cabinet houses 20 maintenance-free lead-acid batteries, each rated at 280W, making it ideal for extending backup power in critical applications. Designed for use with Eaton 9SX UPS systems, this free-standing model ensures reliable power continuity in data centers and server rooms.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Extended Battery Enclosure E-Type Cabinet | 20 x 280W Batteries | Free Standing Black Finish | Eaton
Brand: Eaton
SKU: 9SXEBC280W240
Alternatively Known As: Eaton 9SX Extended Battery Cabinet, Eaton 9SX External Battery Enclosure, Eaton 9SX Battery Expansion Cabinet
Technical Specifications
- Product Type: Extended Battery Enclosure E-type Cabinet
- Battery Quantity: 20
- Battery Type: Lead-acid maintenance-free (replaceable)
- Battery Rating: 280W per battery block
- Input Connection: Hardwired/fixed connection
- Construction: Free standing model
- Color: Black
- Communication: None
- Potential Free Switch Contact: No
- Auto Shutdown Function: No
- Battery Management: No
- Altitude Operating Range: 0-1500m (0° to 40°C), 1500-3000m (0° to 35°C)
- Dimensions (H x L x W): 1530mm x 795mm x 506mm
- Weight: 588 kg
Key Features
- Free standing model with black finish
- Houses 20 lead-acid maintenance-free replaceable batteries
- Battery rating of 280W per battery block
- Hardwired/fixed input connection
- Designed for use with Eaton 9SX UPS
- No auto shutdown function or battery management system included
- Suitable for altitudes 0-1500m at 0° to 40°C and 1500-3000m at 0° to 35°C
Professional Installation Requirements
- Professional installation by qualified technicians is required due to hardwired connections and battery handling.
Applications
- Used with Eaton 9SX UPS systems for extended battery backup
- Suitable for data centers, server rooms, and critical power applications
- Ideal for environments requiring reliable power continuity
Standards & Compliance
- Contact Manufacturer for specific AS/NZS compliance details
Environmental Benefits
- Maintenance-free lead-acid batteries reduce hazardous waste and environmental impact
- Designed for long service life to minimize battery replacements
Warranty Information
1 Year standard factory warranty.
Available Now
The Eaton 9SX Tower 6kVA Extended Battery Enclosure E-type Cabinet is available now for immediate purchase. Ideal for extending backup power capacity in critical UPS applications.
