HIKVISION AX PRO Multi IO Transmitter | 433MHz Wireless | 16 Inputs & 2 Outputs | LED Status Indicator | by Dicker Data
The HIKVISION AX PRO Multi IO Transmitter offers 433MHz wireless communication with 16 onboard inputs and 2 outputs, making it ideal for security systems that require versatile connectivity. Designed for both residential and commercial applications, it features a convenient LED status indicator and two 12V power outputs for external wired detectors, ensuring seamless integration and enhanced security.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HIKVISION AX PRO Multi IO Transmitter | 433MHz Wireless | 16 Inputs & 2 Outputs | LED Status Indicator | by Dicker Data
Brand: Dicker Data
SKU: DS-PM1-I16O2-WB
Alternatively Known As: AX PRO Multi IO Transmitter, Wireless IO Module, Security System IO Transmitter
Technical Specifications
- Frequency: 433MHz two-way wireless communication
- Inputs: 16 onboard inputs
- Outputs: 2 onboard outputs
- Power Outputs: Two 12V outputs for external wired detectors
- Display: LED status indicator
- Backup: Space for backup storage battery
- Dimensions (H x L x W): 100mm x 40mm x 150mm
- Weight: 0.5 kg
Key Features
- 433MHz two-way wireless communication
- LED display showing real-time device status
- 16 onboard inputs and 2 outputs for connecting wired detectors
- Two 12V power outputs for powering external wired detectors
- Large space for backup storage battery
Professional Installation Requirements
- Installation by a qualified security system technician or electrician is recommended to ensure proper integration and compliance with safety standards.
Applications
- Security systems requiring wireless communication and multiple input/output connections
- Integration with wired detectors in residential and commercial security setups
- Powering external wired detectors with onboard 12V power outputs
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Wireless communication reduces the need for extensive wiring, minimizing material waste
- Energy-efficient design lowers power consumption
Warranty Information
2 years warranty from the manufacturer.
Available Now
The HIKVISION AX PRO PM1-I16O2-WB Multi IO Transmitter is available for immediate purchase, ideal for enhancing security systems with wireless and wired detector integration.
