Mini Clamp Meter 400A AC/DC True RMS | Auto-Ranging & Data Hold | Non-Contact Voltage Detection | by Wattmaster
The Mini Clamp Meter 400A AC/DC True RMS is perfect for electrical testing and troubleshooting, featuring auto-ranging capability and a data hold function for convenience. Designed for both industrial and residential use, this handheld meter ensures accurate readings with true RMS technology and non-contact voltage detection, making it a reliable tool for electricians and technicians.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Mini Clamp Meter 400A AC/DC True RMS | Auto-Ranging & Data Hold | Non-Contact Voltage Detection | by Wattmaster
Brand: Wattmaster
SKU: WATEL-CM07
Alternatively Known As: Clamp Meter, Current Clamp Meter, AC/DC Clamp Meter, True RMS Clamp Meter, Digital Clamp Meter
Technical Specifications
- Current Measurement: 400A AC/DC
- True RMS for accurate AC measurements
- Auto-ranging capability
- Data hold function
- Overload protection
- Non-contact voltage detection
- Backlight for display visibility in low light
- Complies with IEC 61010-1 safety standards
- Dimensions (H x L x W): 180mm x 35mm x 70mm
- Weight: 0.3 kg
Key Features
- Handheld digital meter with ruggedised body
- Auto-ranging and auto power off for convenience and battery saving
- Data hold function and overload protection for safety and ease of use
- True RMS measurement for accurate readings on non-linear loads
- Highly efficient fuses and handy backlight for use in dim areas
- Non-contact voltage indication for safe voltage detection
- Complies with IEC 61010-1 safety specifications
Professional Installation Requirements
- No professional installation required; suitable for use by qualified electricians and trained technicians.
Applications
- Electrical testing and troubleshooting
- Industrial and residential electrical maintenance
- HVAC system diagnostics
- Automotive electrical system testing
- General current measurement in AC and DC circuits
Standards & Compliance
- Complies with AS/NZS 61010-1 – Safety requirements for electrical equipment for measurement, control, and laboratory use
Environmental Benefits
- Auto power off feature conserves battery life reducing waste
- Durable design reduces need for frequent replacements
Warranty Information
1 year warranty covering manufacturing defects and workmanship.
Available Now
The Wattmaster Mini Clamp Meter 400A AC/DC True RMS is available for immediate purchase, ideal for electrical testing and maintenance in industrial, commercial, and residential settings.
