Miniature Circuit Breaker 2P 100A 15kA 415V Hager

BRAND: :hager
SKU: HMD290T
$479.60 List price: $597.70
+ −
30 Days Return Electricians Unlock Trade Access
Hager Miniature Circuit Breaker 2P 100A features 15kA breaking capacity, 415V rated. Suited to domestic and commercial switchboards.
Technical Specifications
  • Type of pole: 2P
  • Rated operational voltage: 415 V
  • Rated current: 100 A
  • Rated short-circuit breaking capacity: 15 kA
  • Nominal tightening torque: 3.5 - 5.0 Nm
  • Electric endurance: 4000 cycles
  • Mechanical operations: 20000 cycles
  • Cross-section for massive conductors: 1 - 70 mm²
  • Cross-section for flexible conductors: 1 - 50 mm²
  • Dimensions (H x L x W): 90mm x 70mm x 53mm
  • Weight: 0.5 kg
Key Features
  • 2-pole design for effective circuit protection.
  • Rated short-circuit breaking capacity of 15 kA.
  • Suitable for AC voltage supply up to 415 V.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices and retail spaces
  • Industrial: Factories and manufacturing facilities
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
  • RoHS and REACH compliant, contributing to reduced environmental impact.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager MCB 2P 15kA D-100A 3M is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.

Data Sheet (HMD290T, 159 Kb) [Download]

Certificate (PEP_HAGE-00928-V02.01-EN.pdf, 40,154 Kb) [Download]

Certificate (reach_declaration_HMD290T5.pdf, 103 Kb) [Download]

Certificate (rohs_declaration_HMD290T5.pdf, 104 Kb) [Download]

Data Sheet (HMF299T.webp, 286 Kb) [Download]

Certificate (DECLARATION_21_2310_07_21.pdf, 101 Kb) [Download]

Certificate (DECLARATION_23_3059_05_2023.pdf, 439 Kb) [Download]

Certificate (DECLARATION_23_2310_05_23.pdf, 455 Kb) [Download]
