Miniature Circuit Breaker 3P 100A 15kA 415VAC Hager

BRAND: :hager
SKU: HMC390T
$575.70 List price: $717.40
+ −
30 Days Return Electricians Unlock Trade Access
Hager Miniature Circuit Breaker 3P 100A features 15kA breaking capacity, 415VAC rated. Suited to domestic and commercial switchboards.
Technical Specifications
  • Rated operational voltage: 415V AC
  • Rated insulation voltage: 500V
  • Rated impulse withstand voltage: 6000V
  • Frequency: 50 - 60 Hz
  • Nominal tightening torque: 3.5 - 5.0 Nm
  • Electric current: Rated current 100A
  • Endurance: 4000 electrical operations, 20000 mechanical operations
  • Cross-section of input/output: 1 - 70 mm² for massive conductors, 1 - 50 mm² for flexible conductors
  • Dimensions (H x L x W): 90mm x 70mm x 80mm
  • Weight: 0.5 kg
Key Features
  • 3-pole design for three-phase systems.
  • Rated current of 100A with a breaking capacity of 15kA.
  • Screw terminal connections for secure installation.
  • Suitable for use in various climates.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
  • Complies with AS/NZS 60947-2 for circuit breakers.
Environmental Benefits
  • RoHS and REACH compliant, contributing to reduced environmental impact.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager MCB 3P 15kA C-100A 4.5M is available now for immediate purchase. Ideal for residential and commercial electrical systems.

Data Sheet (HMC390T, 188 Kb) [Download]

Certificate (PEP_HAGER_HAGE-00715-V01.01-EN_23092022.pdf, 377 Kb) [Download]

Certificate (reach_declaration_HMC390T5.pdf, 103 Kb) [Download]

Certificate (rohs_declaration_HMC390T5.pdf, 104 Kb) [Download]

Data Sheet (HMC399T.webp, 356 Kb) [Download]

Certificate (DECLARATION_21_2310_07_21.pdf, 101 Kb) [Download]

Certificate (DECLARATION_23_3059_05_2023.pdf, 439 Kb) [Download]

Certificate (DECLARATION_23_2310_05_23.pdf, 455 Kb) [Download]
