Miniature Circuit Breaker 4P 20A 10kA IP20 400V Hager
Hager Miniature Circuit Breaker 4P 20A features 10kA breaking capacity, IP20 protection and 400V rated. Suited to domestic and commercial switchboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated ultimate short-circuit breaking capacity Icu under 400 V AC: 15 kA
- Rated operational voltage Ue: 400 V
- Rated insulation voltage Ui: 500 V
- Rated impulse withstand voltage Uimp: 6000 V
- Frequency: 50 - 60 Hz
- Total power loss under IN: 10.87 W
- Electric endurance: 4000 cycles
- Mechanical operations: 20000 cycles
- Nominal tightening torque: 2.80 Nm
- Dimensions (H x L x W): 83mm x 70mm x 70mm
- Weight: 0.5 kg
Key Features
- Rated current of 20 A with a breaking capacity of 15 kA.
- 4-pole design suitable for various applications.
- Wide operating temperature range from -25°C to 70°C.
- IP20 ingress protection rating.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Factories and manufacturing facilities
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- RoHS compliant, contributing to reduced environmental impact.
- Commitment to improving environmental performance and reducing carbon footprint.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager MCB 4P 10kA/15kA D-20A 4M is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
