Miniature Circuit Breaker 4P 80A 15kA 415VAC Hager

BRAND: :hager
SKU: HMD480T
$1,080.30 List price: $1,346.30
+ −
30 Days Return Electricians Unlock Trade Access
Hager Miniature Circuit Breaker 4P 80A features 15kA breaking capacity, 415VAC rated. Suited to domestic and commercial switchboards.
Technical Specifications
  • Rated operational voltage: 415V AC
  • Rated insulation voltage: 500V
  • Rated impulse withstand voltage: 6000V
  • Frequency: 50 - 60 Hz
  • Nominal tightening torque: 3.5 - 5.0 Nm
  • Electric current: Rated current 80A
  • Endurance: 4000 electrical cycles, 20000 mechanical operations
  • Cross-section for massive conductors: 1 - 70 mm²
  • Cross-section for flexible conductors: 1 - 50 mm²
  • Dimensions (H x L x W): 90mm x 70mm x 106mm
  • Weight: 0.5 kg
Key Features
  • 4-pole design for three-phase systems
  • Rated current of 80A with a breaking capacity of 15kA
  • Screw terminal connections for secure installation
  • Suitable for use in various climate conditions
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and electrical installations
  • Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
  • RoHS and REACH compliant, contributing to reduced environmental impact.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager MCB 4P 15kA D-80A 6M is available now for immediate purchase. Ideal for residential and commercial electrical installations.

Data Sheet (HMD480T, 166 Kb) [Download]

Certificate (PEP_HAGER_HAGE-00715-V01.01-EN_23092022.pdf, 377 Kb) [Download]

Certificate (reach_declaration_HMD480T5.pdf, 103 Kb) [Download]

Certificate (rohs_declaration_HMD480T5.pdf, 104 Kb) [Download]

Data Sheet (HMD499T.webp, 302 Kb) [Download]

Certificate (DECLARATION_21_2310_07_21.pdf, 101 Kb) [Download]

Certificate (DECLARATION_23_2310_05_23.pdf, 455 Kb) [Download]
