NHP Arclogix Optical RS Arc Detection Relay 5I and 3O Panel Mount

Optical Arc Detection Relay 5I 3O | Fast 7ms Trip | DIN Rail Mount by NHP

BRAND: NHP

SKU: ARCLORS5I3O24VDCPLP

$5,874.60 List price: $7,800.70

+ −

30 Days Return Delivery Options

Optical arc detection relay with 5 inputs and 3 normally open contacts—ideal for industrial and commercial safety systems. Built for rapid response with a 7ms trip duration, ensuring enhanced safety in electrical panels.

Description
Attachments

Product Name/Title: NHP Arclogix Optical RS Arc Detection Relay 5I and 3O Panel Mount

Brand: NHP

SKU: ARCLORS5I3O24VDCPLP

Alternatively Known As: Arc Detection Relay, Optical Arc Relay, NHP Arc Relay

Technical Specifications

Voltage Type for Actuating: AC/DC
Rated Control Supply Voltage (US) at AC 50 Hz: 19-65 V
Rated Control Supply Voltage (US) at DC: 19-85 V
Max Flash to Trip Duration: 7 ms
Number of Inputs: 5
Number of Contacts as Normally Open Contact: 3
Mounting Method: DIN rail
Operating Temperature: -10-55 °C
Storage Temperature: -25-70 °C
Dimensions (H x L x W): 65mm x 124mm x 100mm
Weight: 1.0 kg

Key Features

5 inputs and 3 normally open contacts for versatile applications.
Fast trip duration of 7 ms for enhanced safety.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Arc detection in electrical panels
Commercial: Safety systems in various electrical installations

Standards & Compliance

Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.

Environmental Benefits

Enhances safety in electrical systems, reducing the risk of fire and equipment damage.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP Arclogix Optical RS Arc Detection Relay 5I and 3O Panel Mount is available now for immediate purchase. Ideal for industrial and commercial safety applications.

Non-Returnable & Non-Cancellable

ARCLORS5I3O24VDCPLP-AU-Arclogix-Relay-Datasheet.pdf (ARCLORS5I3O24VDCPLP-AU-Arclogix-Relay-Datasheet.pdf, 376 Kb) [Download]
