Orange Circular Cable 0.6/1kV 4C+E 6mm | LSZH Insulation | Blue Sheath | Per 10m by Eltech
Orange circular cable with 0.6/1kV voltage rating and 6mm conductor size—ideal for power distribution in residential and commercial buildings. Built for safety with low smoke zero halogen (LSZH) insulation, ensuring reduced toxic emissions during fire.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Orange Circular Cable 0.6/1kV 4C+E 6mm – Blue – LSZH
Brand: Eltech
SKU: ELT4060E.2-ENV
Alternatively Known As: 4 Core Power Cable, LSZH Power Cable, 6mm Electrical Cable, Low Smoke Zero Halogen Cable
Technical Specifications
- Voltage Rating: 0.6/1kV
- Conductor Size: 6.0mm
- Number of Cores: 4 cores plus earth (4C+E)
- Outer Sheath Colour: Blue
- Drum Length: 500 meters
- Minimum Order Quantity: 10 meter increments
- Insulation Type: Low Smoke Zero Halogen (LSZH)
- Dimensions (H x L x W): 20mm x 500000mm x 20mm
- Weight: 3.5 kg
Key Features
- 4 cores plus earth conductor (4C+E)
- 6.0mm conductor size
- Low Smoke Zero Halogen (LSZH) insulation for enhanced fire safety
- Blue outer sheath for easy identification
- Suitable for 0.6/1kV voltage rating
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 Wiring Rules to ensure safety and compliance.
Applications
- Power distribution in residential, commercial, and industrial buildings
- Electrical installations requiring low smoke zero halogen cables
- Indoor and outdoor electrical wiring where safety and fire resistance are critical
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low Smoke Zero Halogen (LSZH) insulation reduces toxic gas emissions during fire, improving safety and environmental impact
Warranty Information
Standard manufacturer warranty applies. Please refer to Eltech warranty terms for details.
Available Now
The Eltech Orange Circular Cable 0.6/1kV 4C+E 6mm Blue LSZH is available now for immediate purchase. Ideal for power distribution and electrical installations requiring enhanced fire safety.
