Trade Discount 17%
Orange Circular Power Cable 0.6/1kV 2C+E 6.0mm | LSZH Insulation | Blue Sheath | Per 10m by Eltech
Orange circular power cable with 0.6/1kV voltage rating and 6.0mm² conductor size—ideal for power distribution in residential and commercial settings. Built for safety with low smoke zero halogen (LSZH) insulation, ensuring reduced toxic emissions during fire.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Orange Circular Power Cable 0.6/1kV 2C+E 6.0mm – Blue – LSZH
Brand: Eltech
SKU: ELT2060E.2-ENV
Alternatively Known As: Orange Power Cable 6mm 2C+E LSZH, Blue Power Cable 0.6/1kV, Low Smoke Zero Halogen Power Cable
Technical Specifications
- Voltage Rating: 0.6/1kV
- Conductor Size: 6.0mm²
- Cores: 2 Conductors plus Earth (2C+E)
- Sheath Colour: Blue
- Drum Length: 500m
- Minimum Order Quantity: 10m increments
- Insulation Type: Low Smoke Zero Halogen (LSZH)
- Dimensions (H x L x W): 15mm x 500000mm x 15mm
- Weight: 0.5 kg
Key Features
- Low Smoke Zero Halogen (LSZH) insulation for enhanced safety in case of fire
- Rated voltage: 0.6/1kV suitable for medium voltage power applications
- 2 cores plus earth conductor (2C+E) for reliable power transmission
- Blue outer sheath for easy identification
- Available in 10m increments with 500m drum length
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 Wiring Rules to ensure safety and compliance.
Applications
- Power distribution in residential, commercial, and industrial electrical installations
- Suitable for fixed wiring in buildings and infrastructure requiring low smoke zero halogen cables
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low Smoke Zero Halogen (LSZH) materials reduce toxic gas emissions during fire, improving safety and environmental impact
Warranty Information
Standard manufacturer warranty applies; please refer to Eltech for specific warranty terms.
Available Now
The Eltech Orange Circular Power Cable 0.6/1kV 2C+E 6.0mm Blue LSZH is available now for immediate purchase. Ideal for electrical power distribution in residential, commercial, and industrial applications.
