Rackmount UPS 650VA | 420W Power Capacity | Line-Interactive & User Replaceable Battery | 1U Form Factor by Eaton
The Eaton 5P 650VA rackmount UPS offers 420W power capacity and line-interactive topology—ideal for data centers and server rooms. Built for IT professionals, it features a user-replaceable battery and multiple output receptacles for reliable power management.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Rackmount UPS 650VA | 420W Power Capacity | Line-Interactive & User Replaceable Battery | 1U Form Factor by Eaton
Brand: Eaton
SKU: 9210-3360
Alternatively Known As: Eaton 5P UPS 650VA, Eaton 5P Rackmount UPS, 1U Rack UPS, Eaton 5P 420W UPS
Technical Specifications
- Power Capacity: 650 VA / 420 W
- Input Connection: C14
- Output Receptacles: (4) C13
- Input Voltage Range: 160-294 V (adjustable to 150-294 V)
- Output Voltage Range: 230 V (+6%/-10%)
- Output Frequency: 50/60 Hz
- Nominal Voltage: 230 V (configurable 200/208/220/230/240 V)
- Battery Type: Lead-acid maintenance-free, 12 V / 9 Ah
- Battery Quantity: 1, user replaceable
- Topology: Line-interactive
- Communication Ports: USB (HID), Serial (RS232), Mini-terminal block
- Noise Level: <40 dB at 1 meter
- Form Factor: 1U Rackmount (19 inch)
- Operating Temperature: 0-90% non-condensing humidity
- Efficiency at Max Load: 96%
- Auto Shutdown: Yes
- Phase: Single phase input and output
- Dimensions (H x L x W): 43.2mm x 364mm x 438mm
- Weight: 8.6 kg
Key Features
- Line-interactive UPS topology providing reliable power conditioning
- User replaceable lead-acid maintenance-free battery (12 V / 9 Ah)
- Automatic battery test and deep discharge protection
- Rack-mountable 1U form factor suitable for 19-inch racks
- Multiple output receptacles: (4) C13
- Communication interfaces including USB (HID compliant), Serial (RS232), and mini-terminal block for remote control
- Optional communication card slot for expanded connectivity
- High efficiency at maximum load (96%)
- Low noise level (<40 dB at 1 meter)
- Auto shutdown function for safe power management
Professional Installation Requirements
- Professional installation by qualified IT or electrical personnel is recommended to ensure proper rack mounting, electrical connections, and configuration.
Applications
- Data centers and server rooms
- Network and telecommunications equipment
- Office and IT equipment requiring uninterrupted power
- Rack-mounted electronic devices
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- High efficiency design reduces energy consumption and heat generation
- Maintenance-free battery reduces hazardous waste
- Supports power management software to optimize energy use
Warranty Information
Standard manufacturer warranty applies; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton 5P 650VA / 420W 1U Rackmount UPS with LCD is available now for immediate purchase. Ideal for protecting critical IT and network equipment in rack environments.
