Vacuum Motor Ametek 2 Stage Concave Base to Suit Later VBS Valet

BRAND: Ness
SKU: VAC-204
$446.90 List price: $595.80
+ −
30 Days Return Electricians Unlock Trade Access
Valet Ametek vacuum motor features 2 stage design and a concave base to Suit later model VBS units. Ideal for central vacuum power units.

Alternatively Known As: Valet VAC-204, Ametek Lamb 119678-00, 240V 5.7-inch central vacuum motor, tangential bypass vacuum motor

Technical Specifications
  • Motor Model: Ametek Lamb 119678-00
  • Electrical Supply: 240 V AC, 50/60 Hz
  • Power Level: 1650 W
  • Motor Configuration: Two-stage bypass
  • Air Discharge: Tangential
  • Frame Size: 5.7 inch / 145 mm
  • Bearing Type: Dual ball bearing
  • Speed Control: Single speed, no speed control
  • Application: Later-model Valet VBS central vacuum power units
  • Replacement Brush Kit: Ametek 833423-62
  • Dimensions (H x L x W): 189mm x 145mm x 145mm
  • Weight: 2 kg
Key Features
  • Two-stage design for central vacuum power units
  • Concave base configuration for later-model Valet VBS units
  • Tangential bypass airflow design
  • 240 V AC operation suitable for Australian installations
  • 5.7-inch motor frame with 145 mm diameter
  • Dual ball bearings for serviceable operating life
  • Direct replacement motor identified by Valet as VAC-204
Professional Installation Requirements
  • Installation must be performed by a qualified electrician. Confirm the motor voltage, mounting pattern, wiring and gasket or seal requirements before installation. Incorrect wiring or fitting may void the warranty.
Applications
  • Replacement motor for later-model Valet VBS central vacuum power units
  • Central vacuum system repairs and refurbishment
  • Residential and light commercial ducted vacuum systems using a compatible 240 V motor
Standards & Compliance
  • AS/NZS 60335.2.2:2020 is relevant to the safety of complete centrally-sited vacuum cleaners; motor-specific certification for this replacement component was not stated by the manufacturer.
Environmental Benefits
  • Extends the service life of an existing central vacuum power unit, reducing whole-unit replacement waste
  • Replacement of the motor can avoid disposal of the motor housing, canister and associated system components
  • Efficiently restores the intended operation of a compatible central vacuum system without replacing the complete appliance
Warranty Information

12-month warranty from the date of purchase for spare motors, according to Valet product information.

Available Now

Available through Valet and authorised Australian distributors, subject to current stock availability.
